Real CNC Machining Examples for RFQ Review
These examples show typical CNC turned and machined parts we can review for overseas OEM buyers. Final price, tolerance, and lead time depend on the drawing, material, quantity, and inspection requirements.
Send your drawing for review: STEP, PDF, DXF, DWG, STP, IGES, or ZIP files are supported on the RFQ page.
304 Stainless Steel Shaft
Material: 304 Stainless Steel
Process: CNC turning, facing, chamfering, surface check
Tolerance: +/-0.01mm on critical diameters after drawing review
Quantity: Prototype to repeat batch
Industry: Industrial machinery
Challenge: Maintain shaft straightness and stable diameter control during turning.
Result: Sample approval followed by repeat batch order review.
304 Stainless Steel Threaded Connector
Material: 304 Stainless Steel
Process: CNC turning, threading, deburring
Tolerance: Thread and mating dimensions inspected before shipment
Quantity: Small batch production
Industry: Equipment connector assembly
Challenge: Control thread fit, burrs, and connector edge finish for assembly.
Result: Repeat order after sample confirmation.
Brass Mechanical Sleeve Set
Material: Brass
Process: CNC turning, inner/outer diameter machining, length control
Tolerance: ID / OD / length measurement before shipment
Quantity: Small batch and repeat production
Industry: Mechanical assembly
Challenge: Keep sleeve dimensions consistent across multiple pieces.
Result: Pre-shipment inspection prepared for batch delivery.
Brass Turned Component from Drawing
Material: Brass / copper alloy
Process: Drawing review, CNC turning, groove and chamfer machining
Tolerance: Drawing-based tolerance review before quotation
Quantity: Prototype and batch quotation
Industry: OEM metal component sourcing
Challenge: Translate customer drawing requirements into practical machining steps.
Result: Buyer receives manufacturability feedback before price confirmation.
Small Precision Machined Part
Material: Stainless steel / aluminum / brass options
Process: CNC turning or milling based on geometry
Tolerance: Critical features checked according to drawing
Quantity: Prototype, small batch, or repeat production
Industry: Automation and machinery parts
Challenge: Balance machining cost, tolerance, and delivery time for OEM buyers.
Result: RFQ path supports drawing upload and engineering review.
How to Use These Case Studies
- Compare your part material, process, and tolerance with the examples above.
- Upload your drawing if your part has threads, tight tolerance, long shaft geometry, or special surface requirements.
- We will review manufacturability before confirming quotation and lead time.
